Gen4 LS Drive-By-Wire & Fuse Box Bundle: G4X XtremeX ECU + LS Engine Harness bundle

Name: Gen4 LS Drive-By-Wire & Fuse Box Bundle: G4X XtremeX ECU + LS Engine Harness bundle
Brand: Link Engine Management
SKU: 109-9025B
Price: 4944.50 AUD
Availability: InStock

SKU:109-9025B

$4,944.50 AUD

Sale Sold out

Taxes included.

View full details

Product information

A ready-to-go solution to connect a Link ECU to your Gen 4, Drive-By-Wire LS V8 engine. (LS2, LS3, LS7 & LSA)

Bundle Includes:

G4X Xtreme X ECU (8 x Injector and 8 x Ignition Drives) - 109-4000
Terminated Engine Harness GM LS Gen 3/4* - 101-0300
LS drive-By-Wire Adapter Loom - 101-0304
LS Gen4 Knock Adapter Loom - 101-0306
LS Gen4 MAP Adapter Harness - 101-0308
LS Cam Sensor Adapter Harness - 101-0307
8x Bosch Male to Female Adapters - 101-0287
LS Fuse Box & Relay - 101-0310

Advanced features of the XtremeX ECU:

Fully programmable E-throttle control complete with capability of gear shift throttle blip and antilag.
Cruise control.
Two independent CAN modules.
30 general purpose tables (up from 20)
All Motorsport features including full gear shift control, cruise control, traction control, antilag and launch control.
Advanced closed loop lambda strategy and dual bank lambda control.

The terminated harness has the following features:

Provides spare IO via a “Spares” connector — extra capacity for sensors, switches, or custom additions.
With the addition of the fusebox, this package Includes main chassis “flying leads” (un‐terminated wires) for essential power and control, including:Large red “Batt+” wire (for ECU main power) Red-Green “Fan” wire (ECU-controlled +12V to cooling fan), rated 20A continuous Red-Blue “Fuel Pump” wire (ECU-controlled +12V), 20A continuous Grey-Black “Ign Sw” wire (to ignition switch)
Equipped with sealed JPT terminals in the chassis connector (TE Connectivity JPT family), with mating connector specs provided.
